| Model | HSH-A0.75T | HSH-A1.5T | HSH-A3T | HSH-A6T | HSH-A9T | |
| Capacity | kg | 750.00 | 1500.00 | 3000.00 | 6000.00 | 9000.00 |
| Standard Lifting Height | m | 1.50 | 1.50 | 1.50 | 1.50 | 1.50 |
| Test load | kg | 1125.00 | 2250.00 | 4500.00 | 9000.00 | 13500.00 |
| Effort Requirde to Lift Rated Load | N | 250.00 | 310.00 | 410.00 | 420.00 | 420.00 |
| Strands of Load Chain | 1.00 | 1.00 | 2.00 | 3.00 | 4.00 | |
| Diameter of Load Chain | Dia×Pitch | 6×18 | 8×24 | 10×30 | 10×30 | 10×30 |
| Min. Distance Between Two Hooks | mm | 440.00 | 550.00 | 650.00 | 650.00 | 780.00 |
| Handle Length | mm | 285.00 | 410.00 | 410.00 | 410.00 | 410.00 |
| Dimensions (mm) | A | 155.00 | 190.00 | 200.00 | 200.00 | 210.00 |
| B | 120.00 | 140.00 | 150.00 | 150.00 | 150.00 | |
| C | 130.00 | 150.00 | 200.00 | 220.00 | 340.00 | |
| D | 37.00 | 45.00 | 55.00 | 65.00 | 75.00 | |
| K | 35.00 | 42.00 | 42.00 | 45.00 | 68.00 | |
| Net Weight | kg/pc | 6.70 | 11.00 | 17.50 | 25.50 | 49.80 |
