| Art No. | Size | ASTM80 | NACM90 | NACM96 | ||||||
| Weight | WLL | BL | Weight | WLL | BL | Weight | WLL | BL | ||
| inch | kg/pc | lb | lb | kg/pc | lb | lb | kg/pc | lb | lb | |
| G43 | ||||||||||
| CH05-1/4X14G43 | 1/4" X 14' | 5.0 | 2150 | 7750 | 4.5 | 2600 | 7500 | 4.5 | 2600 | 7800 |
| CH05-1/4X16G43 | 1/4" X 16' | 6.0 | 2150 | 7750 | 5.0 | 2600 | 7500 | 5.0 | 2600 | 7800 |
| CH05-5/16X14G43 | 5/16" X 14' | 7.5 | 3200 | 11600 | 6.0 | 3900 | 9700 | 7.0 | 3900 | 11700 |
| CH05-5/16X16G43 | 5/16" X 16' | 8.5 | 3200 | 11600 | 6.5 | 3900 | 9700 | 8.0 | 3900 | 11700 |
| CH05-5/16X18G43 | 5/16" X 18' | 9.5 | 3200 | 11600 | 7.5 | 3900 | 9700 | 9.0 | 3900 | 11700 |
| CH05-5/16X20G43 | 5/16" X 20' | 10.5 | 3200 | 11600 | 8.0 | 3900 | 9700 | 9.5 | 3900 | 11700 |
| CH05-5/16X25G43 | 5/16" X 25' | 13.0 | 3200 | 11600 | 10.0 | 3900 | 9700 | 12.0 | 3900 | 11700 |
| CH05-5/16X30G43 | 5/16" X 30' | 15.5 | 3200 | 11600 | 12.0 | 3900 | 9700 | 14.0 | 3900 | 11700 |
| CH05-3/8X14G43 | 3/8" X 14' | 10.5 | 4450 | 16200 | 9.5 | 5400 | 15200 | 10.0 | 5400 | 16200 |
| CH05-3/8X16G43 | 3/8" X 16' | 12.0 | 4450 | 16200 | 11.0 | 5400 | 15200 | 11.5 | 5400 | 16200 |
| CH05-3/8X20G43 | 3/8" X 20' | 15.0 | 4450 | 16200 | 13.5 | 5400 | 15200 | 13.5 | 5400 | 16200 |
| CH05-3/8X25G43 | 3/8" X 25' | 18.5 | 4450 | 16200 | 16.5 | 5400 | 15200 | 17.5 | 5400 | 16200 |
| G70 | ||||||||||
| CH05-1/4X14G70 | 1/4" X 14' | 5.0 | 3150 | 12600 | 4.5 | 3150 | 12100 | 4.0 | 3150 | 12600 |
| CH05-1/4X16G70 | 1/4" X 16' | 6.0 | 3150 | 12600 | 5.0 | 3150 | 12100 | 5.0 | 3150 | 12600 |
| CH05-5/16X14G70 | 5/16" X 14' | 7.5 | 4700 | 18800 | 7.0 | 4700 | 18800 | 7.0 | 4700 | 18800 |
| CH05-5/16X16G70 | 5/16" X 16' | 8.5 | 4700 | 18800 | 8.0 | 4700 | 18800 | 8.0 | 4700 | 18800 |
| CH05-5/16X18G70 | 5/16" X 18' | 9.5 | 4700 | 18800 | 9.0 | 4700 | 18800 | 9.0 | 4700 | 18800 |
| CH05-5/16X20G70 | 5/16" X 20' | 10.5 | 4700 | 18800 | 10.0 | 4700 | 18800 | 10.0 | 4700 | 18800 |
| CH05-5/16X25G70 | 5/16" X 25' | 13.0 | 4700 | 18800 | 12.0 | 4700 | 18800 | 12.0 | 4700 | 18800 |
| CH05-5/16X30G70 | 5/16" X 30' | 15.5 | 4700 | 18800 | 14.0 | 4700 | 18800 | 14.5 | 4700 | 18800 |
| CH05-3/8X14G70 | 3/8" X 14' | 10.5 | 6600 | 26400 | 9.5 | 6600 | 24700 | 10.0 | 6600 | 26400 |
| CH05-3/8X16G70 | 3/8" X 16' | 12.0 | 6600 | 26400 | 11.0 | 6600 | 24700 | 11.5 | 6600 | 26400 |
| CH05-3/8X20G70 | 3/8" X 20' | 15.0 | 6600 | 26400 | 13.5 | 6600 | 24700 | 14.5 | 6600 | 26400 |
| CH05-3/8X25G70 | 3/8" X 25' | 18.5 | 6600 | 26400 | 16.5 | 6600 | 24700 | 18.5 | 6600 | 26400 |
