| Art No. | Nominal | Tolerance | Min. Breaking Strength | Approx. | |
| Diameter | on Dia. | Weight | |||
| inches | inches | lb | lb/1000ft | kg/1000ft | |
| WP10-1/16 | 1/16" | 0.010 | 500 | 8.5 | 3.86 |
| WP10-3/32 | 3/32" | 0.012 | 1,200 | 20.0 | 9.07 |
| WP10-1/8 | 1/8" | 0.014 | 2,100 | 35.0 | 15.88 |
| WP10-5/32 | 5/32" | 0.016 | 3,300 | 55.0 | 24.95 |
| WP10-3/16 | 3/16" | 0.018 | 4,700 | 77.0 | 34.93 |
| WP10-1/4 | 1/4" | 0.018 | 8,200 | 135.0 | 61.24 |
| WP10-5/16 | 5/16" | 0.022 | 12,500 | 210.0 | 95.26 |
| WP10-3/8 | 3/8" | 0.026 | 18,000 | 300.0 | 136.08 |
