| Model | HSZ-KT0.5 | HSZ-KT1 | HSZ-KT1.5 | HSZ-KT2 | HSZ-KT3 | HSZ-KT5 | HSZ-KT10 | HSZ-KT20 | HSZ-KT30 | HSZ-KT50 | |
| Capacity | Ton | 0.50 | 1.00 | 1.50 | 2.00 | 3.00 | 5.00 | 10.00 | 20.00 | 30.00 | 50.00 |
| Standard Lift | m | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 |
| Running Test Load | KN | 7.50 | 15.00 | 22.50 | 45.00 | 45.00 | 62.50 | 125.00 | 250.00 | 375.00 | 625.00 |
| Effort Requirde to Lift Rated Load | N | 200.00 | 320.00 | 360.00 | 365.00 | 385.00 | 435.00 | 435.00 | 870.00 | 870.00 | 870.00 |
| Diameter of Load Chain | mm | 5.00 | 6.30 | 7.10 | 8.00 | 7.10 | 9.00 | 9.00 | 9.00 | 9.00 | 9.00 |
| Dimensions (mm) | A | 113.00 | 140.00 | 161.00 | 161.00 | 161.00 | 183.00 | 207.00 | 215.00 | 350.00 | 406.00 |
| B | 127.00 | 158.00 | 187.00 | 187.00 | 210.00 | 253.00 | 398.00 | 650.00 | 680.00 | 962.00 | |
| C | 270.00 | 317.00 | 399.00 | 414.00 | 465.00 | 636.00 | 798.00 | 890.00 | 1380.00 | 2578.00 | |
| D | 35.00 | 40.00 | 45.00 | 50.00 | 58.00 | 64.00 | 85.00 | 110.00 | 110.00 | 110.00 | |
| K | 30.00 | 34.00 | 38.00 | 41.00 | 48.00 | 52.00 | 64.00 | 85.00 | 85.00 | 130.00 | |
| Net Weight | kg/pc | 8.40 | 11.00 | 16.20 | 18.50 | 25.60 | 42.80 | 79.50 | 193.00 | 220.00 | 1092.00 |
| Extra Weight Per Meter of Extra Lift | kg | 1.70 | 1.70 | 2.30 | 2.30 | 3.70 | 5.60 | 9.70 | 19.40 | 26.40 | 48.40 |
