| Model | HSZ-K0.5 | HSZ-K1 | HSZ-K1.5 | HSZ-K2 | HSZ-K3 | HSZ-K5 | HSZ-K10 | HSZ-K20 | |
| Capacity | Ton | 0.50 | 1.00 | 1.50 | 2.00 | 3.00 | 5.00 | 10.00 | 20.00 |
| Standard Lift | m | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 |
| Running Test Load | KN | 7.50 | 15.00 | 22.50 | 30.00 | 45.00 | 77.00 | 150.00 | 300.00 |
| Effort Requirde to Lift Rated Load | N | 231.00 | 309.00 | 320.00 | 360.00 | 340.00 | 414.00 | 414.00 | 828.00 |
| Strands of Load Chain | 1.00 | 1.00 | 1.00 | 1.00 | 2.00 | 2.00 | 4.00 | 8.00 | |
| Diameter of Load Chain | mm | 6.00 | 6.00 | 8.00 | 8.00 | 8.00 | 10.00 | 10.00 | 10.00 |
| Dimensions (mm) | A | 131.00 | 140.00 | 161.00 | 161.00 | 161.00 | 86.00 | 207.00 | 215.00 |
| B | 127.00 | 158.00 | 187.00 | 187.00 | 210.00 | 253.00 | 398.00 | 650.00 | |
| C | 270.00 | 317.00 | 399.00 | 414.00 | 465.00 | 636.00 | 798.00 | 890.00 | |
| Hook Opening | mm | 30.00 | 34.00 | 38.00 | 40.00 | 48.00 | 52.00 | 64.00 | 85.00 |
| Net Weight | kg/pc | 11.25 | 11.20 | 17.40 | 22.20 | 26.20 | 37.70 | 72.00 | 160.00 |
