| Art No. | WLL | Type | Hook | EYE | B | C | Wire Rope | Weight |
| Ton | A1mm | A2mm | mm | mm | mm | kg/pc | ||
| BL06-3X1 | 0.20 | 3"x1 | 203.00 | 164.00 | 57.00 | 39.00 | 12.00 | 0.90 |
| BL06-3X2 | 0.40 | 3"x2 | 203.00 | 164.00 | 60.00 | 62.00 | 12.00 | 0.90 |
| BL06-4X1 | 0.40 | 4"x1 | 262.00 | 232.00 | 76.00 | 45.00 | 16.00 | 1.20 |
| BL06-4X2 | 0.90 | 4"x2 | 262.00 | 232.00 | 76.00 | 70.00 | 16.00 | 2.10 |
| BL06-4X3 | 1.00 | 4"x3 | 262.00 | 232.00 | 76.00 | 83.00 | 16.00 | 2.60 |
| BL06-5X1 | 0.50 | 5"x1 | 278.00 | 270.00 | 92.00 | 49.00 | 18.00 | 2.00 |
| BL06-5X2 | 1.10 | 5"x2 | 280.00 | 272.00 | 92.00 | 74.00 | 18.00 | 3.00 |
| BL06-5X3 | 1.50 | 5"x3 | 280.00 | 272.00 | 92.00 | 100.00 | 18.00 | 4.00 |
| BL06-6X1 | 1.00 | 6"x1 | 346.00 | 340.00 | 112.00 | 60.00 | 24.00 | 3.50 |
| BL06-6X2 | 2.00 | 6"x2 | 346.00 | 340.00 | 112.00 | 102.00 | 24.00 | 6.20 |
| BL06-7X1 | 1.10 | 7"x1 | 388.00 | 35.00 | 62.00 | 64.00 | 28.00 | 5.10 |
| BL06-7X2 | 2.30 | 7"x2 | 388.00 | 350.00 | 128.00 | 101.00 | 28.00 | 7.60 |
| BL06-8X1 | 1.30 | 8"x1 | 415.00 | 390.00 | 163.00 | 68.00 | 30.00 | 7.60 |
| BL06-8X2 | 2.60 | 8"x2 | 415.00 | 390.00 | 163.00 | 111.00 | 30.00 | 11.30 |
| BL06-9X1 | 1.50 | 9"x1 | 450.00 | 420.00 | 180.00 | 75.00 | 32.00 | 11.40 |
| BL06-9X2 | 3.00 | 9"x2 | 450.00 | 420.00 | 180.00 | 123.00 | 32.00 | 16.80 |
| BL06-10X1 | 1.80 | 10"x1 | 492.00 | 460.00 | 200.00 | 75.00 | 34.00 | 13.40 |
| BL06-10X2 | 3.00 | 10"x2 | 492.00 | 460.00 | 200.00 | 117.00 | 34.00 | 19.30 |
