| Art No. | Nominal Diameter | Nominal Tensile Strength | Approx. Weight | ||||
| 1570N/mm2 | 1770N/mm2 | ||||||
| Minimum Breaking Strength (KN) | kg/m | ||||||
| mm | FC | IWRC | FC | IWRC | FC | IWRC | |
| WP06-08 | 8 | 33.1 | 35.8 | 37.3 | 40.3 | 0.243 | 0.268 |
| WP06-10 | 10 | 51.7 | 55.9 | 58.3 | 63.0 | 0.380 | 0.418 |
| WP06-12 | 12 | 74.4 | 80.6 | 84.0 | 89.9 | 0.547 | 0.602 |
| WP06-13 | 13 | 87.4 | 94.6 | 98.3 | 106.0 | 0.643 | 0.707 |
| WP06-14 | 14 | 101.0 | 109.0 | 114.0 | 124.0 | 0.745 | 0.820 |
| WP06-16 | 16 | 133.0 | 143.0 | 149.0 | 161.0 | 0.973 | 1.070 |
| WP06-18 | 18 | 168.0 | 181.0 | 189.0 | 204.0 | 1.230 | 1.350 |
| WP06-20 | 20 | 203.0 | 221.0 | 234.0 | 252.0 | 1.520 | 1.670 |
| WP06-22 | 22 | 250.0 | 271.0 | 282.0 | 304.0 | 1.840 | 2.020 |
| WP06-24 | 24 | 298.0 | 322.0 | 336.0 | 363.0 | 2.190 | 2.410 |
| WP06-26 | 26 | 340.0 | 378.0 | 395.0 | 425.0 | 2.570 | 2.830 |
| WP06-28 | 28 | 405.0 | 438.0 | 458.0 | 493.0 | 2.980 | 3.280 |
| WP06-32 | 32 | 530.0 | 571.0 | 598.0 | 644.0 | 3.890 | 4.280 |
| WP06-36 | 36 | 670.0 | 724.0 | 757.0 | 816.0 | 4.930 | 5.420 |
| WP06-40 | 40 | 828.0 | 894.0 | 935.0 | 1008.0 | 6.080 | 6.690 |
| WP06-44 | 44 | 1000.0 | 1080.0 | 1130.0 | 1220.0 | 7.360 | 8.100 |
