| Art No. | Rope Diameter | Nominal Breaking Strength | Approx. Weight | ||
| Nominal | Maximum | Uncoated | Galvanized | ||
| (minimum) | |||||
| inches | inches | lb | lb | lb/ft | |
| WP01-1/4 | 1/4" | 0.265 | 5,280 | 4,760 | 0.094 |
| WP01-5/16 | 5/16" | 0.328 | 8,200 | 7,380 | 0.150 |
| WP01-3/8 | 3/8" | 0.394 | 11,720 | 10,540 | 0.210 |
| WP01-7/16 | 7/16" | 0.459 | 15,860 | 14,280 | 0.290 |
| WP01-1/2 | 1/2" | 0.525 | 20,600 | 18,540 | 0.380 |
| WP01-9/16 | 9/16" | 0.591 | 26,000 | 23,400 | 0.480 |
| WP01-5/8 | 5/8" | 0.656 | 31,800 | 28,600 | 0.590 |
| WP01-3/4 | 3/4" | 0.788 | 45,400 | 40,800 | 0.840 |
